|Group||Stainless steel parts|
|Price||US $1.5-5 / piece|
|Min. Order||1 piece|
|Terms of Payment||Western Union, T/T, Paypal|
|Name||CNC machining parts|
|Item Name||Precision CNC service machining parts|
|Quality Assurance||ISO9001:2008 Certified|
|Main Equipment||The capacity of equipment involve DMG 5-axis Machining centers, Mazak 5-axis machine,YASDA YBM-8120V,DMG CNC universal turning machines, 4-axis and 3-axis Machining centers, Sodick wire cutting machine, Mitutoyo CMM and etc. More than 40 high grade machining and testing equipment of all kinds.|
|5052 /6061/ 6063 / 2017 / 7075 / etc.|
|3602 / 2604 / H59 / H62 / etc.|
|Stainless Steel Alloy:|
|303 / 304 / 316 / 412 / etc.|
|Carbon Steel / Die Steel / Spring Steel etc.|
|Other Special Materials:|
|Lucite / Nylon / Bakelite / POM / ABS / PP / PC / PE / PEEK / Titanium etc.|
|We handle many other type of materials. Please contact us if your required material is not listed above.|
|Surface Treatment||Blacking,polishing,anodize,chrome plating,zinc plating,nickel plating,tinting|
|Inspection||Mitutoyo three-coordinate measuring machine / Mitutoyo tool microscope/digimatic micrometer/inside micrometer/go-no go gauge/dialgage/ electronic digital display caliper/automatic height gauge/ precision level 2 detector/precision block gauge/00 levels of marble platform/ring gauge|
|File Formats||The production drawings can be sent in CAD, DXF, STEP, IGES, x_t and other formats, supporting the use of CAD, Soildwork UG ProE and other softwares.|
|Enterprise certification||14 national patents: The waste recovery patent The circuit welding patent The waste recovery patentThe leakproof patentThe power patent The fixed device patent The laser engraving patentThe jig patentThe top plate patentThe oil water separation patent|
|Customer distribution|| |
Thank you for your attention. Our clients are mainly in Japan, Germany, USA, UK, Canada, Sweden and FinlandLAN, Belgium, Australia, Russia, India, Turkey, Austria, Netherlands, Portugal, Spain, Switzerland,Denmark, Norway, New Zealand, Malaysia, Egypt, Peru, Mexico, Singapore, Saudi Arabia, Mauritius,Peru, Zambia, el Salvador, Israel and more than 40 countries and regions). Japan accounts for 70 percent of the market, Europe and the United States account for15%, others 15%
The use of Tool Microscope
Making smaller, customized service workpieces, dimensional measurements are usually made on a 2D plane. For example, measuring the aperture and hole spacing with the size of around φ1mm, the position where the gauge can not touched, and the relatively weak measurement contact surface. The product local details can be enlarged by using the tool microscope for an accurate measurements.
The use of CMM Multi-Joint Arm
Measurements are made for workpieces that are inconvenient to move, or for workpieces that are not being reassembled on the equipment. When there is a similar product, the measuring arm can be moved and used as long as it is fixed on a stable surface and calibrated. The function is similar to the three-coordinate detector, but it is more flexible.
The use of high precision automatic measuring machine
Common tools for inspection and final inspection, easy to operate.Taking the marble platform as the benchmark,It is usually used to measure the height of the workpiece, the overall dimensions, the dimensions between the surface and the surface, and the dimensions between the center and the surface.The precision is about 0.005-0.01mm.
Rockwell hardness tester
Hardness testing is an important part of product testing. According to the customer's processing requirements, if the product need to heat treatment.We will arrange the heat treatment outsourcing factory for processing.The products after heat treatment should be sent to the quality inspection room for hardness test.The next step of the process can not be carried out until the product is qualified. (in the figure, the quality inspector is testing the hardness.)
The use of Ordinary Measuring Implement
The most common test method at work. The measuring tool includes a micrometer, an inner diameter micrometer, a digital caliper, a depth gauge, a through stop gauge, a feeler gauge, a gauge block, and the like. After the test personnel get the product to be inspected, they will conduct a full inspection according to the requirements of the drawings. After the test is passed, they will be covered with their own name. Finally, the inspection drawings with the name of the inspector will be delivered to the customer with the product in order to trace the quality of the product.
